General
Form Factor: | Micro-ATX |
Expansion Slots: | 5 |
Interior Painting: | ✓ |
Tool-Free Devices Installation: | ✓ |
Cable Management System: | ✓ |
Side Panel: | Tempered Glass |
VGA Holder: | ✓ |
Weight & Dimensions
Weight: | 6.1 kg |
Dimensions (L x W x H): | 43.5 x 22.5 x 44.5 cm |
RGB Compatibility
Type: | Addressable |
Ports: | 4 |
Manual Control: | 22 Modes |
Mainboard Compatibility: | MSI Mystic Light Sync, ASUS Aura Sync, Gigabyte RGB Fusion Ready, ASRock Polychrome Sync |
RGB pinout: | 5V-D-coded-G |
Max. Drive Bays
3.5": | 2 |
2.5": | 4 |
I/O
Type-C (USB 3.2 Gen 2): | 1 |
USB 3.0 (Left): | 2 |
Audio (Left): | TRRS |
Fan Configuration
Side Panel: | 2x 120 mm Addressable RGB LED PWM Fan (Pre-installed) or Radiator* (Optional) |
Rear Panel: | 1x 120 mm Addressable RGB LED PWM Fan (Pre-installed) |
Top Panel: | 3x 120 mm or 2x 140 mm Fan or Radiator (Optional) |
Bottom Panel: | 2x 120 mm Fan (Optional) |
PWM Fan Hub: | 4-Port |
Compatibility
Mainboard: | Mini-ITX, Micro-ATX (BTF) |
Max. Length Graphics Cards: | 41.0 cm |
Max. Height CPU Cooler: | 17.0 cm |
Max. Length PSU: | 23.5 cm |
Max. Height Radiator incl. Fan (Top): | 6.0 cm |
Note
* A graphics card length of more than 26 cm may conflict with radiator installation on side panel
- Case Type
- Midi Tower
- Motherboard Support
- Micro ATX / Mini-ITX
